Material Dispersion
Internal structure and washing method matched to stickiness and clay content.
Screening & Washing
Rotary Screening & Washing Equipment
The rotating drum tumbles and disperses material while separating particle sizes. Washing, spray bars, feeding, conveying and recovery stages can be configured around material stickiness, particle-size range, clay content and the target process.
Equipment FormatFixed or integrated
Main FunctionsScreening · Washing · Sizing
ConfigurationDesigned for the material
SupportFabrication · Installation · Repair
Selection Basis
Conditions required for selection
Capacity, drum dimensions, screen openings, power and auxiliary equipment must be determined after the project requirements are reviewed.
| Material Data | Material name, maximum particle size, size distribution, clay and moisture content, and abrasiveness. |
|---|---|
| Treatment Goal | Washing, screening, sizing, desliming or integration with a downstream recovery process. |
| Site Conditions | Available space, foundation, water and power supply, feed and discharge direction, and transport limits. |
| Key Parameters | Capacity, drum specification, screen-opening combination and drive power are subject to the approved proposal. |
| Optional Equipment | Hopper, feeder, conveyor, spray system, dewatering or recovery equipment. |
| Service Scope | Solution design, fabrication, installation, commissioning, operation guidance and repair support. |
Design Focus
What the design must address
The structure must account for blockage, wear, cleaning and routine maintenance in addition to target throughput.
Particle-Size Control
Screen openings and staged separation configured around the target sizes.
System Integration
Coordinate feeding, discharge, conveying, dewatering and recovery rates.
Need a rotary screening and washing solution?
Material photographs, particle-size data and the treatment target help accelerate selection.
